Description
Advanced Biometric Authentication
The DS-K1T342MFWX gives organizations multiple ways to authenticate employees and authorized users.
Face Recognition
The integrated 2 MP wide-angle camera provides fast face authentication with a recognition distance of 0.3 to 1.5 metres.
Face recognition takes less than 0.2 seconds per user, with an accuracy rate greater than 99% according to Hikvision’s datasheet.
Fingerprint Recognition
The terminal supports up to 3,000 fingerprints and provides fingerprint recognition in less than one second.
This makes it suitable for employee attendance and secure door access applications where fingerprint authentication is preferred.
MIFARE Card Authentication
The built-in M1 card reader operates at 13.56 MHz and supports M1 cards.
The card reading distance is up to 5 cm for normal cards, while the reading duration is less than one second.
Ideal for Time Attendance
The DS-K1T342MFWX can also be used as a biometric time attendance terminal.
Employees can clock in and out using:
- Face recognition
- Fingerprint
- MIFARE card
The device supports an attendance-only function, making it suitable for employee attendance deployments as well as access control installations.
Secure Door Access Control
The terminal provides the interfaces needed for integration with a door access system.
Available interfaces include:
- Lock control
- Exit button
- Door contact
- RS-485
- Wiegand
- USB
- Tamper
- RJ-45 network connection
This allows the DS-K1T342MFWX to be deployed as part of a complete door access control solution.
Built for African Environments
With an operating temperature range of -30°C to 60°C and an IP65 protective rating, the DS-K1T342MFWX is designed for demanding environments.
It can be deployed in:
- Offices
- Warehouses
- Factories
- Construction sites
- Schools
- Hotels
- Hospitals
- Retail businesses
- Commercial buildings
- Industrial facilities
- Government organizations
- Staff accommodation
- Financial institutions
Technical Specifications
| Specification | DS-K1T342MFWX |
|---|---|
| Product Type | Face Recognition / Fingerprint Access Terminal |
| Authentication | Face, Fingerprint, M1 Card |
| Face Capacity | 1,500 |
| Fingerprint Capacity | 3,000 |
| Card Capacity | 3,000 |
| Event Capacity | 150,000 |
| Display | 4.3-inch LCD |
| Touchscreen | Capacitive |
| Display Resolution | 272 × 480 |
| Camera | 2 MP |
| Face Recognition Distance | 0.3–1.5 m |
| Face Recognition Speed | < 0.2 sec/user |
| Face Recognition Accuracy | >99% |
| Fingerprint Recognition Speed | <1 sec |
| Card Type | M1 |
| Card Frequency | 13.56 MHz |
| Card Reading Distance | 0–5 cm |
| Network | TCP/IP |
| Wi-Fi | 2.4 GHz 802.11b/g/n |
| Network Interface | 1 × RJ-45 10/100 Mbps |
| Protocols | ISAPI, ISUP 5.0 |
| RS-485 | 1 |
| Wiegand | 1 |
| USB | 1 |
| Lock Control | 1 |
| Exit Button | 1 |
| Door Contact | 1 |
| Tamper | 1 |
| Two-Way Audio | Supported |
| Face Anti-Spoofing | Supported |
| Mask Recognition | Supported |
| Multi-Factor Authentication | Supported |
| Protection Rating | IP65 |
| Operating Temperature | -30°C to 60°C |
| Operating Humidity | 0–90%, non-condensing |
| Power Supply | 12 VDC, 1 A |
| Installation | Wall mounting |
| Dimensions | 91.3 × 181.3 × 24.5 mm |
| Operating System | Linux |
| RAM | DDR3 512 MB |
| ROM | 4 GB |
| Platform | Hik-ProConnect, HikCentral Professional |
Specifications based on Hikvision’s DS-K1T342MFWX datasheet dated May 6, 2026.
Network & Software Integration
The DS-K1T342MFWX supports TCP/IP and 2.4 GHz Wi-Fi, making it suitable for both wired and wireless network deployments.
It supports ISAPI and ISUP 5.0 protocols for integration and centralized management. Configuration can be performed through the web client.
The terminal is also compatible with Hik-ProConnect and HikCentral Professional.
Applications
Corporate Offices
Secure employee access while automatically recording attendance.
Factories & Warehouses
Control access to restricted areas and monitor workforce attendance.
Schools & Universities
Manage staff access and attendance using biometric authentication.
Hotels & Commercial Buildings
Provide secure access control for employees and authorized users.
Healthcare Facilities
Control access to staff-only areas and maintain attendance records.
Construction & Industrial Sites
Use biometric authentication to improve workforce access management.
Why Buy from TACS Africa?
TACS Africa provides biometric access control, time attendance and security technology solutions for businesses and organizations across Africa.
We can supply the Hikvision DS-K1T342MFWX as a standalone terminal or as part of a complete biometric access control and attendance solution.
TACS Africa Services
- Biometric access control systems
- Face recognition systems
- Fingerprint attendance systems
- RFID card access systems
- Employee time attendance systems
- Door lock installation
- Access control software
- Network configuration
- System integration
- Installation and commissioning
- Technical support
Complete Biometric Access Control Solution
The DS-K1T342MFWX can be integrated with:
Biometric Terminal → Door Lock → Exit Button → Door Sensor → Network → Access Control / Attendance Software
TACS Africa can help design and install the complete system according to your project requirements.
Frequently Asked Questions
What is the Hikvision DS-K1T342MFWX?
The DS-K1T342MFWX is a Hikvision biometric face recognition terminal supporting face, fingerprint and M1 card authentication.
How many users can the terminal support?
It supports up to 1,500 faces, 3,000 fingerprints and 3,000 cards. It can store up to 150,000 events.
Can the DS-K1T342MFWX be used for time attendance?
Yes. The terminal supports an attendance-only function and can be used for employee attendance using face, fingerprint or card authentication.
Does it support Wi-Fi?
Yes. It supports 2.4 GHz 802.11b/g/n Wi-Fi as well as wired TCP/IP networking.
Does it support MIFARE cards?
Yes. The built-in reader supports M1 cards at 13.56 MHz.
Is the terminal suitable for outdoor environments?
The terminal has an IP65 protective rating and an operating temperature range of -30°C to 60°C. However, installation conditions should still be assessed to ensure the device is protected from unsuitable exposure and environmental conditions.
Does it support HikCentral?
Yes. The datasheet lists HikCentral Professional and Hik-ProConnect as supported platforms.
Can TACS Africa install the system?
Yes. TACS Africa can provide supply, installation, configuration and integration support for biometric access control and attendance projects.
Request a Quote
Hikvision DS-K1T342MFWX
Upgrade your organization’s access control and employee attendance with face recognition, fingerprint and MIFARE card authentication in one professional terminal.
Contact TACS Africa for pricing, availability, installation and complete biometric access control solutions.
Request a Quote Today
